TypeScript Discriminated Unions: Make Invalid States Impossible

A union on each field lets a type describe states that should never exist. A discriminated union describes each valid state as its own object shape, tagged by a literal field. TypeScript then narrows the whole object when you check that field.

The problem: independent unions

type SelectProps = {
  multiple: boolean;
  value: string | string[];
  onChange: (value: string | string[]) => void;
};

This type accepts multiple: false with value: ['a', 'b']. Every consumer has to check Array.isArray(value) or cast, and nothing ties onChange to the mode in use.

The fix: one tag decides the shape

type SelectProps =
  | {
      multiple: true;
      value: string[];
      onChange: (value: string[]) => void;
    }
  | {
      multiple?: false;
      value: string;
      onChange: (value: string) => void;
    };

multiple is the discriminant. Its literal type (true or false | undefined) selects which object you have, and the other fields follow. The mismatched combination is now a compile error:

// Error: Type 'string[]' is not assignable to type 'string'.
<Select value={['a']} onChange={() => {}} />

Narrowing in a React component

function Select(props: SelectProps) {
  if (props.multiple) {
    // props.value: string[], props.onChange: (value: string[]) => void
    return <p>{props.value.join(', ')}</p>;
  }
  // props.value: string
  return <p>{props.value}</p>;
}

export function Demo() {
  return (
    <div>
      <Select value="a" onChange={(v) => console.log(v.toUpperCase())} />
      <Select multiple value={['a', 'b']} onChange={(v) => console.log(v.length)} />
    </div>
  );
}

At the call site, v is inferred as string or string[] from the props you pass. No annotations, no casts.

Destructuring keeps narrowing (TypeScript 4.6+) when you destructure the discriminant and the fields together: ({ multiple, value }: SelectProps) works. A rest spread does not: in ({ multiple, ...rest }), checking multiple leaves rest.value as string | string[].

Exhaustiveness with never

When a union grows a variant, you want every switch that handles it to fail compilation until it is updated:

type Shape =
  | { kind: 'circle'; radius: number }
  | { kind: 'rect'; width: number; height: number };

function area(shape: Shape): number {
  switch (shape.kind) {
    case 'circle':
      return Math.PI * shape.radius ** 2;
    case 'rect':
      return shape.width * shape.height;
    default:
      return assertNever(shape);
  }
}

function assertNever(value: never): never {
  throw new Error(`Unhandled variant: ${JSON.stringify(value)}`);
}

After the handled cases, shape is narrowed to never. Add { kind: 'triangle'; base: number; height: number } to Shape and the default branch fails with “Argument of type { kind: "triangle"; ... } is not assignable to parameter of type never”. The runtime throw covers data that bypassed the types, such as an unvalidated API response.

Exhaustiveness for lookup tables with satisfies

For maps keyed by the tag, satisfies checks that every key exists while keeping the literal type of the object:

type RequestState =
  | { status: 'idle' }
  | { status: 'loading' }
  | { status: 'success'; data: string[] }
  | { status: 'error'; error: Error };

const statusLabel = {
  idle: 'Not started',
  loading: 'Loading',
  success: 'Done',
  error: 'Failed',
} satisfies Record<RequestState['status'], string>;

function describe(state: RequestState): string {
  if (state.status === 'success') return `${state.data.length} items`;
  if (state.status === 'error') return state.error.message;
  return statusLabel[state.status];
}

Remove the loading key and the compiler reports Property 'loading' is missing. Add a 'cancelled' status and statusLabel fails until you label it.

When not to use one

• The fields really are independent. If any combination is valid, a union of shapes just multiplies cases.
• The variants differ by one optional field. { id: string; deletedAt?: Date } reads better than two shapes.
• The data comes from outside your code. A discriminated union describes what you expect, not what arrives. Parse at the boundary (for example, with a Zod discriminatedUnion) and use the type after validation.
• The variant count keeps growing across modules. Every switch becomes an edit site. If new kinds are added often by different teams, an interface with per-kind implementations may age better.

Rule of thumb

If you find yourself writing Array.isArray, in, or as to recover which state you are in, the type has lost information you had when you created the value. Put it back as a tag.
